Multi Jet Dry Dial Plastic Water Meter
Certificate: ISO9001: 2000 Quality System Certificate
Application
Measuring the volume of cold potable water passing through the pipeline.
Plastic Water Meter Features
Completely plastic shell, solid and robust design, long service guaranteed.
High quality materials corrosion resistance.
Pole ring magnet polymer coating as protection against deposits.
The measuring mechanism can be exchanged.
Anti-magnet.
Inside calibration device.
Large measuring range high flow accuracy.
Steady curve characteristics.
Measuring accuracy is up to ISO4064, Class B.
Overload flowrate: QS=2Qp (Qn=nominal flowrate)
WORKING CONDITION
Water temperature: Less than or equal to 40ºC
Water pressure: Less than or equal to 1.6MP(16bar)
MAXIMUM PERMISSIBLE ERROR
In the lower zone from qmin inclusive up to but excluding qt is ± 5 percent
In the upper zone from qt inclusive up to and including QS is ± 2 percent
ACCESSORIES
Optional: Both brass thread connections and plastic thread connections are available.
